The FLTCON-4 is a 4-channel hall effect control box, designed to function with four identical 24VDC hall effect linear actuators and lifting column systems. Our PA-03, PA-04, and PA-18 linear actuators can be customized to have a hall effect feedback sensor as well as a 24VDC motor. Our  units are readily available in 24 VDC and come standard with the hall effect sensor required for the FLTCON series control boxes.

Using the wired remote with presets, the user can extend, stop, and retract the , as well as program up to 4 preset positions with the  handset remote (sold separately). It can also act as a replacement control box for our FLT-04 table lift set.

The FLTCON series does not include a wired remote, please see our  section to choose the most suitable remote for the application.
